Inner height hi: 15mm
Inner widths Bi: 10 - 50mm
Bend radii R: 25 - 48mm
Pitch: 20mm
1. Small pitch for quiet, smooth running
2. High torsional rigidity
3. Light and low priced
4. Dirt-repellent outer contours
5. Mounting bracket with strain relief option
6. Single-component design
7. Easy to fill option
8. Openable option
9. Enclosed e-tube
Series 08 is suitable for the following types of applications:
Vertical: Hanging applications, standing applications
Horizontal: Unsupported applications ≤ 0.6 m
Circular movement: Rotating application possible, if necessary with reworking (from 180° rotation angle mechanical reworking is always necessary)
Vertical: Hanging applications, standing applications
Horizontal: Unsupported applications ≤ 0.6 m
Circular movement: Rotating application possible, if necessary with reworking (from 180° rotation angle mechanical reworking is always necessary)
- When a small e-chain® with 15 mm inner height and smallest bend radii is required
- For inner widths up to 50mm
- For unsupported lengths up to 1.0m and fill weights up to 0.7kg/m
- Quiet operation due to small pitch
- When high torsion strength is required
- When a one-sided, non-openable e-chain® is required
- If interior separation is required
- When the opening of chain links is necessary
- When easy filling with connectors is required
- When an enclosed e-tube is required
